Heavy Duty Gabion Box Making Machine
heavy duty gabion box making machine
Vertical-weave architecture. Thick-gauge wire. Mechanical reliability for year-round production.
The heavy duty gabion box making machine is a vertical-weave platform built for wire diameters and sustained production volumes that exceed the operational limits of horizontal machines.
Where horizontal models suit short-cycle contracts on standard wire gauges, the heavy duty machine is designed for factories running year-round gabion production — slope protection, flood control, riverbank reinforcement, and large-scale infrastructure supply chains.
Mechanical drive system. High-torque components engineered for thick-gauge wire at continuous throughput — without the complexity or cost of servo automation.
Heavy Duty Gabion Box Making Machine Specifications
All parameters are configurable. Wire diameter range, weaving width, and mesh aperture are confirmed at the time of order and fixed at manufacture.
| Mesh Size | Wire Diameter | Max Mesh Width | Number of Twists | Production Speed | Motor Power | Weight | Dimensions (L×W×H) |
|---|---|---|---|---|---|---|---|
| 60×80 mm | 1.0 – 3.0 mm | 2300 mm | 3 / 5 | 165 m/h | 11 kW | 13 t | 5200×1400×2400 mm |
| 60×80 mm | 1.0 – 3.0 mm | 3300 mm | 3 / 5 | 165 m/h | 15 kW | 14 t | 6200×1400×2400 mm |
| 60×80 mm | 1.0 – 3.0 mm | 4300 mm | 3 / 5 | 165 m/h | 22 kW | 15 t | 7200×1400×2400 mm |
| 60×80 mm | 1.0 – 3.5 mm | 2300 mm | 3 / 5 | 195 m/h | 11 kW | 13 t | 5200×1400×2400 mm |
| 60×80 mm | 1.0 – 3.5 mm | 3300 mm | 3 / 5 | 195 m/h | 15 kW | 14 t | 6200×1400×240 mm |
| 60×80 mm | 1.0 – 3.5 mm | 4300 mm | 3 / 5 | 195 m/h | 22 kW | 15 t | 7200×1400×2400 mm |
| 60×80 mm | 1.0 – 4.0 mm | 2300 mm | 3 / 5 | 225 m/h | 11 kW | 13 t | 5200×1400×2400 mm |
| 60×80 mm | 1.0 – 4.0 mm | 3300 mm | 3 / 5 | 225 m/h | 15 kW | 14 t | 6200×1400×2400 mm |
| 60×80 mm | 1.0 – 4.0 mm | 4300 mm | 3 / 5 | 225 m/h | 22 kW | 15 t | 7200×1400×2400 mm |
Mesh opening size is fixed at manufacture. Wire diameter range must be confirmed before order — heavy duty configurations are optimized for the specified gauge range and cannot be re-calibrated for significantly lighter wire after manufacture.
Heavy Duty Gabion Box Making Machine — Production Footage
This footage shows the heavy duty gabion box making machine running thick-gauge wire through a complete vertical-weave production cycle. Wire feed tension, twist formation on heavy gauge, and panel output dimensions are all visible under normal production conditions.
If you would like to view more project cases, learn about real application sites, or need expert advice to choose the right heavy-duty gabion mesh machine for your needs, please feel free to contact us. Our team is ready to provide customized solutions for your project.
Why Choose the Heavy Duty Gabion Box Making Machine
Vertical-Weave Architecture for Thick-Gauge Wire
Horizontal machines are optimized for standard wire gauges — typically up to 3.5 mm. Beyond that threshold, mechanical stress on horizontal weaving heads increases sharply, reducing component life and output consistency. The vertical-weave architecture distributes wire tension differently — gravity assists the weave, rather than working against it. The result: thick-gauge production at continuous throughput without accelerated wear on critical twisting components.
The Infrastructure Supply Chain Standard
Gabion boxes used in permanent civil engineering — dam reinforcement, highway slope protection, flood control embankments — are typically specified to EN 10223-3 or ASTM A975 standards. The heavy duty machine’s wire diameter range and twist geometry are configured to produce mesh that meets these standards, making it the specified machine for contractors supplying regulated infrastructure markets.
Output Scale Matched to Infrastructure Contracts
The heavy-duty machinery is designed to continuously weave thick-gauge steel wire in each shift—completing work on thousands of square meters within a specified time. A single heavy-duty machine can convey up to 225 meters per hour, and two shifts are sufficient to meet the supply needs of large-scale infrastructure projects, which typically require multiple horizontal machines.
Lower Capital Cost Than CNC Equivalent
The heavy duty mechanical model delivers the same vertical-weave architecture, wire diameter range, and maximum weaving width as the CNC version — at a lower purchase price. For operations where a single mesh specification runs continuously and twist-type switching is not required, the mechanical model’s cost advantage is significant without any output compromise.
Mechanical Reliability for Year-Round Production
The mechanical drive system on the heavy duty model is engineered for sustained operation — not intermittent short-cycle runs. High-torque components, reinforced weaving heads, and extended maintenance intervals are designed for factories where the machine runs every working day. No servo calibration drift. No PLC parameter reset after power interruption. Consistent output from day one through year three.
Production Line Layout and Workshop Requirements
A complete heavy duty gabion mesh production line consists of four components arranged in sequence:
Packaging, Export Documentation, and Delivery
Every heavy duty gabion box making machine is prepared for international freight before leaving our Hebei facility.
Reinforced wooden export crates with protective film on all exposed mechanical and painted surfaces. Engineered for sea freight, rail, and multimodal transport without damage to components or finish.
